#include <windows.h>
#include <stdio.h>
#include <cstdint>
#include <chrono>
#include <vector>

Go to the source code of this file.

Classes
struct	asdk::frame_t
	A decoded video or photo frame, delivered by FrameFunc. More...
struct	asdk::video_options_t
	Encoder settings in effect on the sending client, delivered by VideoOptionsFunc. More...
struct	asdk::video_mode_t
	What the sending client is currently doing, delivered by VideoModeFunc. More...
struct	asdk::audio_options_t
	Audio encoder settings, see sdk_t::SetAudioOptions and sdk_t::AudioOptions. More...
struct	asdk::audio_frame_t
	Decoded room audio, delivered by DecodedAudioFrameFunc. More...
struct	asdk::position_klv_values_t
	Platform and sensor position decoded from MISB ST 0601 KLV. More...
struct	asdk::position_nmea_values_t
	Position decoded from an NMEA 0183 GNSS receiver. More...
struct	asdk::position_values_t
	Position reported by the sending client, delivered by PositionValuesFunc. More...
struct	asdk::bandwidth_statistics_t
	Full set of transport counters for one reporting period. More...
struct	asdk::bandwidth_statistics_simple_t
	Throughput of the active connection, delivered by BandwidthStatisticsFunc. More...
struct	asdk::certificate_t
	A server certificate, as filled in by sdk_t::RequestCertificate. More...
struct	asdk::sdk_t
	SDK Core. More...

Namespaces
namespace	asdk

Macros
#define	ASDK_WINDOWS
#define	ASDK_LoadLib(a)
#define	ASDK_GetProc(a1, a2)
#define	ASDK_FreeLib(a)
#define	ASDK_CALL __cdecl
#define	ASDK_SAFE_ALIAS

Typedefs
typedef void *	asdk::hsdk
typedef uint32_t	asdk::RoomFlagValue
typedef uint32_t	asdk::RoomStateValue
typedef uint8_t	asdk::UserCapabilityValue
typedef int	asdk::DeviceCapabilityValue
typedef uint8_t	asdk::AudioFrameStateValue
typedef struct asdk::position_klv_values_t	asdk::position_klv_values_t
typedef struct asdk::position_nmea_values_t	asdk::position_nmea_values_t
typedef struct asdk::position_values_t	asdk::position_values_t
typedef struct asdk::bandwidth_statistics_t	asdk::bandwidth_statistics_t
using	asdk::TimePoint = std::chrono::high_resolution_clock::time_point
using	asdk::TimeMS = std::chrono::milliseconds
using	asdk::TimePointSteady = std::chrono::steady_clock::time_point
typedef struct asdk::certificate_t	asdk::certificate_t
typedef void(*)	asdk::ServerStateFunc(const ServerState serverState, void *opaque)
	The connection to the server changed state.
typedef void(*)	asdk::RoomAnnounceFunc(const char roomName, const uint32_t roomID, const asdk::RoomStateValue state, const asdk::RoomFlagValue flags, void opaque)
	A room was announced after RequestRoomListSubscribe, or an announced room changed.
typedef void(*)	asdk::RoomResponseFunc(const Request request, const RoomResponse response, const void optionalData, const uint32_t optionalDataSize, void opaque)
	The server answered a request sent with SendRequest or SendRequestStr.
typedef void(*)	asdk::RoomClientAddedFunc(const uint32_t clientID, const char userName, const UserCapabilityValue userCapability, const DeviceCapabilityValue deviceCapability, void opaque)
	A client joined the room, and once for each member already present when this client joined.
typedef void(*)	asdk::RoomClientRemovedFunc(const uint32_t clientID, void *opaque)
	A client left the room, identified by the clientID given by RoomClientAdded.
typedef void(*)	asdk::AuthenticateResponseFunc(const AuthenticationResponse authenticateResponse, void *opaque)
	The server answered the login, see AuthenticationResponse for the bits.
typedef void(*)	asdk::FrameFunc(const frame_t frame, void opaque)
	A video or photo frame was decoded to RGB.
typedef void(*)	asdk::EncodedStreamFunc(const StreamType type, const void data, const uint32_t dataSize, void opaque)
	An encoded frame or stream chunk arrived, before any decoding.
typedef void(*)	asdk::EncodedAudioFrameFunc(const uint16_t srcID, const unsigned int timeStamp, const asdk::AudioFrameStateValue state, const unsigned char audioEncoded, const size_t audioEncodedSize, void opaque)
	An encoded audio frame arrived, before any decoding.
typedef void(*)	asdk::VideoOptionsFunc(const video_options_t videoOptions, void opaque)
	The sending client reported its encoder settings, see video_options_t.
typedef void(*)	asdk::VideoModeFunc(const video_mode_t videoMode, void opaque)
	The sending client switched photo mode, ROI or streaming on or off.
typedef void(*)	asdk::PositionValuesFunc(const position_values_t positionValues, void opaque)
	The sending client reported a position, see position_values_t.
typedef void(*)	asdk::BandwidthStatisticsFunc(const bandwidth_statistics_simple_t bandwidthStatistics, void opaque)
	Periodic throughput report for the active connection.
typedef void(*)	asdk::RoomPreviewImageFunc(const uint32_t roomID, const uint64_t utc, const ImageFormat imageFormat, const uint8_t data, const uint32_t size, void opaque)
	A room preview image arrived for a room announced with RoomStatePreview.
typedef void(*)	asdk::RoomFileAvailableFunc(const uint32_t roomID, const uint64_t hash, const char fileName, const uint32_t fileSize, const uint32_t originClientID, const uint64_t utc, void opaque)
	A room file became available to download (pull model).
typedef void(*)	asdk::RoomFileDeletedFunc(const uint32_t roomID, const uint64_t hash, void *opaque)
	A room file (roomID, hash) was deleted for the whole room; drop any reference to it.
typedef void(*)	asdk::RoomFileDownloadedFunc(const uint32_t roomID, const uint64_t hash, const char fileName, const uint8_t data, const uint32_t size, void *opaque)
	A requested room-file download finished and hash-verified: data/size hold the file bytes (valid only for the duration of the callback).
typedef void(*)	asdk::RoomFileProgressFunc(const uint32_t roomID, const uint64_t hash, const char fileName, const RoomFileDirection direction, const uint32_t transferred, const uint32_t total, void opaque)
	Bytes moved for a transfer in either direction.
typedef void(*)	asdk::RoomFileSentFunc(const uint32_t roomID, const uint64_t hash, const char fileName, void opaque)
	An upload reached the server, which now announces it to the other room members.
typedef void(*)	asdk::RoomFileErrorFunc(const uint32_t roomID, const uint64_t hash, const char fileName, const RoomFileError error, void opaque)
	A transfer failed, anything already received for it has been discarded.
typedef void(*)	asdk::ChatMessageFunc(const uint32_t clientID, const char message, const uint32_t size, void opaque)
	A chat message was received from the joined room.
typedef void(*)	asdk::DecodedAudioFrameFunc(const audio_frame_t audioFrame, void opaque)
	A received audio frame was decoded to PCM.
typedef struct asdk::sdk_t	asdk::sdk_t

Enumerations
enum	asdk::Status { asdk::StatusUndef , asdk::StatusOK , asdk::StatusDisconnected , asdk::StatusError , asdk::StatusErrorHandle , asdk::StatusErrorVideoModule , asdk::StatusErrorImageModule , asdk::StatusErrorInitialized , asdk::StatusErrorConnect , asdk::StatusErrorTransmit , asdk::StatusErrorAudioModule , asdk::StatusErrorFile , asdk::StatusErrorNotPermitted }
	Result of an SDK call. More...
enum	asdk::ServerState { asdk::ServerStateUndef , asdk::ServerStateDisconnected , asdk::ServerStateConnected , asdk::ServerStateConnectedAndAuthenticated , asdk::ServerStateAuthenticateError }
	State of the connection to the server, reported by ServerStateFunc. More...
enum	asdk::AuthenticationResponse { asdk::AuthenticationResponseUndef = 0 , asdk::AuthenticationResponseSuccess = 1 << 0 , asdk::AuthenticationResponseError = 1 << 1 , asdk::AuthenticationResponseVersionError = 1 << 2 , asdk::AuthenticationResponseVersionRecUpgrade = 1 << 3 , asdk::AuthenticationResponseVersionMayUpgrade = 1 << 4 , asdk::AuthenticationResponseLoggedInOther = 1 << 5 , asdk::AuthenticationResponseKickedOther = 1 << 6 , asdk::AuthenticationResponseWrongLoginType = 1 << 7 , asdk::AuthenticationResponseTryAgainLater = 1 << 8 , asdk::AuthenticationResponseFormatError = 1 << 9 , asdk::AuthenticationResponseRequestedCapError = 1 << 10 }
	Outcome of a login attempt, reported by AuthenticateResponseFunc. More...
enum	asdk::Request { asdk::RequestUndef , asdk::RequestRoomListSubscribe , asdk::RequestRoomListUnsubscribe , asdk::RequestRoomJoin , asdk::RequestRoomLeave }
	Request sent with sdk_t::SendRequest or sdk_t::SendRequestStr. More...
enum	asdk::RoomResponse { asdk::RoomResponseUndef , asdk::RoomResponseSuccess , asdk::RoomResponseError , asdk::RoomResponseErrorAlreadyJoined , asdk::RoomResponseErrorUnhandled }
	Server answer to a Request, reported by RoomResponseFunc. More...
enum	asdk::RoomFlag { asdk::RoomFlagUndef , asdk::RoomFlagIsPublic = 1 << 0 , asdk::RoomFlagChatGuests = 1 << 1 , asdk::RoomFlagChatViewers = 1 << 2 , asdk::RoomFlagChatSenders = 1 << 3 , asdk::RoomFlagAudioGuests = 1 << 4 , asdk::RoomFlagAudioViewers = 1 << 5 , asdk::RoomFlagAudioSenders = 1 << 6 }
	What a room permits, announced by RoomAnnounceFunc as a RoomFlagValue. More...
enum	asdk::RoomState { asdk::RoomStateUndef , asdk::RoomStatePassword = 1 << 0 , asdk::RoomStatePreview = 1 << 1 }
	State of a room, announced by RoomAnnounceFunc as a RoomStateValue. More...
enum	asdk::RoomFileDirection { asdk::RoomFileDirectionUndef , asdk::RoomFileDirectionSend , asdk::RoomFileDirectionReceive }
	Room file transfer direction. More...
enum	asdk::RoomFileError { asdk::RoomFileErrorUndef , asdk::RoomFileErrorCanceled , asdk::RoomFileErrorHashMismatch , asdk::RoomFileErrorFile }
	Room file transfer failure reason. More...
enum	asdk::PositionSource { asdk::PositionSourceUndefined , asdk::PositionSourceNMEA , asdk::PositionSourceKLV }
	Which member of position_values_t carries the position. More...
enum	asdk::StreamType { asdk::StreamTypeUnknown , asdk::StreamType264Frame , asdk::StreamType265Frame , asdk::StreamTypeAV1Frame , asdk::StreamTypeMPEGTS , asdk::StreamTypeWEBP }
	Kind of payload delivered by EncodedStreamFunc. More...
enum	asdk::ImageFormat { asdk::ImageFormatUndef , asdk::ImageFormatJPEG , asdk::ImageFormatWEBP , asdk::ImageFormatHEIF , asdk::ImageFormatAVIF , asdk::ImageFormatAV1 , asdk::ImageFormatH265 }
	Encoding of the image delivered by RoomPreviewImageFunc. More...
enum	asdk::UserCapability : uint8_t { asdk::UserCapabilityUndef = 0 , asdk::UserCapabilitySender = 1 << 0 , asdk::UserCapabilityController = 1 << 1 , asdk::UserCapabilityViewer = 1 << 2 , asdk::UserCapabilityGuest = 1 << 3 , asdk::UserCapabilitySuper = 1 << 6 , asdk::UserCapabilityUnsure = 1 << 7 }
	The role a client asks the server for on connect. More...
enum	asdk::DeviceCapability : int { asdk::DeviceCapabilityUndef = 0 , asdk::DeviceCapabilityVideoAV1 = 1 << 1 , asdk::DeviceCapabilityVideoH264 = 1 << 2 , asdk::DeviceCapabilityVideoH265 = 1 << 3 , asdk::DeviceCapabilityAudioOpus = 1 << 4 , asdk::DeviceCapabilityAudioSpeex = 1 << 5 , asdk::DeviceCapabilityAudioMIC = 1 << 6 , asdk::DeviceCapabilityPhotoModeWEBP = 1 << 7 , asdk::DeviceCapabilityPhotoModeHEIF = 1 << 8 , asdk::DeviceCapabilityPhotoModeAVIF = 1 << 9 , asdk::DeviceCapabilityPhotoROI = 1 << 10 , asdk::DeviceCapabilityVideoROI = 1 << 11 , asdk::DeviceCapabilityChat = 1 << 12 , asdk::DeviceCapabilityDisplay = 1 << 13 , asdk::DeviceCapabilityFileTransfer = 1 << 16 , asdk::DeviceCapabilityASIGN = 1 << 31 , asdk::DeviceCapabilityBasic , asdk::DeviceCapabilityCore , asdk::DeviceCapabilityFull , asdk::DeviceCapabilityHeadless }
	What a client announces it can do, as a DeviceCapabilityValue. More...
enum	asdk::AudioFrameState { asdk::AudioFrameStateUndef = 0 , asdk::AudioFrameSpeex = 1 << 0 , asdk::AudioFrameOpus = 1 << 1 , asdk::AudioFrameServer = 1 << 2 }
	Codec and origin of an encoded audio frame, as an AudioFrameStateValue. More...
enum	asdk::AudioCodec { asdk::AudioCodecUndef , asdk::AudioCodecOpus , asdk::AudioCodecSpeex }
	Audio codec enum, the encoder used by sdk_t::SendAudioFrame. More...
enum	asdk::CertificateState { asdk::CertificateStateUndef , asdk::CertificateStateConnected , asdk::CertificateStateReceived , asdk::CertificateStateConnectError }
	Outcome of sdk_t::RequestCertificate. More...

Functions
TimePoint	asdk::TimeNow ()
	Current high resolution clock reading.
long long	asdk::TimeSpent (const TimePoint &timeStart)
	Milliseconds elapsed since a TimeNow() reading.
TimePointSteady	asdk::TimeNowSteady ()
	Current steady clock reading, unaffected by clock adjustments.
long long	asdk::TimeSpentSteady (const TimePointSteady &time)
	Milliseconds elapsed since a TimeNowSteady() reading.
sdk_t *	asdk::Initialize ()
	Loads the SDK shared library and creates an SDK handle.

Variables
static const uint8_t	asdk::VERSION_MAJOR = 2
static const uint8_t	asdk::VERSION_MINOR = 0
static const uint8_t	asdk::VERSION_PATCH = 1
static const uint32_t	asdk::CHAT_MESSAGE_LEN = 256
static const uint32_t	asdk::AUDIO_SAMPLE_RATE = 16000
static const uint32_t	asdk::AUDIO_CHANNELS = 1
static const uint32_t	asdk::AUDIO_FRAME_SAMPLES = 320

Macro Definition Documentation

◆ ASDK_WINDOWS

#define ASDK_WINDOWS

Definition at line 83 of file asmirasdk.h.

◆ ASDK_LoadLib

#define ASDK_LoadLib ( a )

Value:

(asdk::hsdk)LoadLibraryA(a)

asdk::hsdk

void * hsdk

Definition asmirasdk.h:127

Definition at line 86 of file asmirasdk.h.

Referenced by asdk::Initialize().

◆ ASDK_GetProc

#define ASDK_GetProc	(		a1,
			a2 )

Value:

GetProcAddress((HINSTANCE__*)a1, a2)

Definition at line 89 of file asmirasdk.h.

Referenced by asdk::Initialize().

◆ ASDK_FreeLib

#define ASDK_FreeLib ( a )

Value:

FreeLibrary((HINSTANCE__*)a)

Definition at line 92 of file asmirasdk.h.

Referenced by asdk::Initialize(), and asdk::sdk_t::Unload().

◆ ASDK_CALL

#define ASDK_CALL __cdecl

Definition at line 94 of file asmirasdk.h.

Referenced by asdk::Initialize().

◆ ASDK_SAFE_ALIAS

#define ASDK_SAFE_ALIAS

Definition at line 121 of file asmirasdk.h.
